PL1030-16
Specification:
| MODEL | PL1030-16 | |
Norminal impedance | 8 | Ohm |
| Power capacity | 250 | W |
| Sensitivity(1W/1m) | 93 | dB |
| Frequency Range | 40-4000 | Hz |
| Voice Coil Diameter | 3"(75mm) | |
| Voice Coil Material | Copper | |
| Voice Coil Winding Depth | 18.5 | mm |
| magnet gap depth | 8 | |
| Basket | Cast Aluminum | |
| Effect.diaphragm diameter D | 212 | mm |
| THIELE - SMALL PARAMETERS4 | ||
| Resonance frequency Fs | 50.4 | Hz |
| DC resistance Re | 11.2 | ohm |
| Mechanical facto Qms | 8.45 | |
| Electrical factor Qes | 0.4 | |
| Total factor Qts | 0.38 | |
| BL Factor BL | 19.6 | T.m |
| Effective Moving Mass Mms | 43.2 | gr |
| Equivalent Cas air load Vas | 40.3 | liters |
| Effettive piston area Sd | 0.035 | m2 |
| Max. linear excursion (mathematical) Xmax | ±5.25 | mm |
| Voice -C coil inductance @ 1KHz Le | 1.6 | mH |
| MOUNTING INFORMATION | ||
| Overall Diameter | 262 | mm |
| Bolt Circle Diameter | 246 | mm |
| Baffle Cutout Diameter | 232 | mm |
| Mounting holes diameter | 8-∅6.5 | mm |
| Overall depth: | 121 | mm |
| Net Weight | 5 | kg |
